Price range: $3.57 through $7.98 inc GST
Built to strengthen shelf spans and prevent deflection, the 1200mm shelf support bar is essential for deeper bays using chipboard or MDF panels. These front-to-back bars sit between beams and help distribute weight evenly across the shelf surface.
Why use a shelf support bar?
✅ Boosts Capacity: Reduces mid-span deflection and increases UDL performance
✅ Improves Shelf Longevity: Minimises sagging and damage over time
✅ Simple Install: Sits straight between beams and
✅ Essential for deeper shelves: Particularly 900–1200mm deep, where sag is more likely
| Attribute | Details |
|---|---|
| Nominal Length | 1200mm shelf depth |
| Actual Length | 1158mm (OA) |
| Material | 1.5mm thick pre-galvanised steel |
| Components | 1 x bracing bar + 2 x cleats (fitted on-site) |
| Use | Sits front-to-back between beams, beneath the shelf panel |
| Recommended Quantity | 2–4 per shelf |
| Weight | 1.15kg |
| Finish | Pre-galvanised |
Always use 2 or more support bars per shelf — never use a single bar.
Position bars evenly spaced, avoiding overhangs greater than 25% of the span.
Ideal for use with 18mm MDF, particleboard, or melamine shelf inserts.
| Weight | N/A |
|---|---|
| Length (mm) | 1200, 600, 900 |
